DC20000 Split

Split-System, Air Conditioner Series

48 Volt DC

Detailed Specifications

Maximum Cooling Capacity: 20,000 BTU
Size Condenser – Inches: 35Lx20Wx15H
Size Evaporator – Inches: 26Lx15.5Wx10H
Size Condenser – mm: 890Lx508Wx381H
Size Evaporator – mm: 660Lx394Wx254H
Input Voltage: 48 VDC
Power Consumption: 1200 Watts
DC 20000 Split Weight: 91 lbs / 41 kg
Refrigerant: R134A
Low Voltage Protection: Yes
Controls: Thermostat Standard
Coating: Powder Coated or Galvanized Steel Standard
